| Brushless servomotor 750W | |||
|---|---|---|---|
| with brake | Encoder type | Weigth (Kg) | Length L(mm) |
| SMC80S-0075-30MBK-3LSU | 16 bit single turn magnetoelectric encoder | 3.4 |
158.5+-1.5
|
| Flange (mm) | 80 |
| Shaft diameter (mm) | 14 |
| DC bus voltage (V) | 300 |
| Continuous operating performance | Rated power 750 W |
| Nominal torque (Nm) | 2.39 |
| Nominal speed (Rpm) | 3000 |
| Rated current (A) | 3.8 |
| Maximum torque (Nm) | 7.17 |
| Max current (A) | 11.4 |
| Standstill torque (Nm) | 2.63 |
| Current at stop (A) | 4.2 |
| Winding resistance (ohm) | 2.1 |
| Winding inductance (mH) | 10.5 |
| Electrical time constant (ms) | 5 |
| Electrical time constant (ms) | 0.9 |
| Constant Reverse voltage (V/krpm) | 40 |
| Constant torque (Nm/A) | 0.662 |
| Motor moment of inertia (Kg.cm2) | 1.099 |
| Brake holding torque | 3.2 |
| Number of pole pairs | 3 |
| Maximum transient voltage du/dt (KV/us) | 8 |
| Insulation class | F |
| Maximum radial force (N) | 335 |
| Maximum axial force (N) | 167.5 |
| Cooling | Completely closed, uncooled |
| Protection sign | IP65 for motor body, IP54 for axes |
| Environmental operating conditions |
-20°C ~ 40°C (non-freezing)
|
| Humidity | Below 90% RH (non-condensing) |
| Keep away from active and combustible gases, oil splashes and dust | |
| Altitude | Max Altitude 4000m |
Accessories
Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.
Specifications
| Brand | Kinco |
| Torque | 2.39 Nm (7.17 Nm peak) |
| Power | 750 W |
| Voltage | 230 VAC |
| Shaft diameter | 19 mm |
| Rotor inertia | 1.099 kg/cm2 |
| Body length | 158 mm |
| Weight | 3.4 kg |
| Nominal speed | 3000 rpm (5000 rpm max.) |
| Intensity | 3.8 A (11.4 A max.) |
| Frame size | 80 mm |
| Encoder type | 16 bit single turn |
