External Linear Stepper Motor - Nema 17, 4mm pitch, 150 mm length

Linear axis External motor
Motor: Nema 17 - 0.26Nm - 12V / 0.4A - 4 wires
Screw: diameter 8mm - pitch 4mm - length 150 mm
POM (PolyOxyMethylene) nut

69.69 € Without Taxes 69.69 EUR 69.69 €

69.69 €

83.63 € 83.63 € with taxes

  • Brand
  • NEMA
  • Torque
  • Number of phases
  • Number of phases
  • Current
  • Phase resistance (Ohms)
  • Phase inductance (mH)
  • Body length
  • Screw length
  • Screw diameter
  • Screw step
  • Screw type
  • Weight

This combination does not exist.

Product Documents

Datasheet M17HSL0026-0804E-150

Internal Reference: M17HSL0026-0804E-150

M17HSL0026-0804E-150  is a linear axis composed of a Nema 17 motor on the side, and a 150mm long screw with a diameter of 8mm and a 4mm pitch.

The screw is fixed to the motor, a POM (PolyOxyMethylene) fixing nut moves along the screw.


Electrical Specification

Manufacturer Part Number  M17HSL0026-0804E-150
Motor Type External Linear Stepper
Step Angle 1.8°
Holding Torque 26Ncm(36.8oz.in)
Rated Current/phase 0.4A
Phase resistance  30ohms
Recommended Voltage 12V
Inductance 37mH±20%(1KHz)

Physical Specifications

Frame size 42 x 42mm
Motor length 34mm
Lead Screw Length 150mm
Lead Screw Diameter Φ8mm
Lead/Revolution 4mm
Number of Leads 4
Lead Length 400mm
Weight 220g


Board connector A C B D


Your Dynamic Snippet will be displayed here... This message is displayed because you did not provided both a filter and a template to use.


Brand Soprolec
Torque 0.26 Nm
Number of phases 2, 2
Current 0.4 A
Phase resistance (Ohms) 30 Ohms
Phase inductance (mH) 37 mH
Body length 34 mm
Screw length 150 mm
Screw diameter 8 mm
Screw step 4 mm
Screw type Non captive
Weight 220 gr
